Cambium cnpilot e410 AC1300 Mbps Gigabit Dual Band Access point
Product Id: 29.02.912.04
Brand
Cambium
Quick Overview
- Network Standards - IEEE 802.11a,b,g,n,ac, Wave 2, 802.11 h,d,r,u,w
- Data Transfer Rates - 1267 Mbps
- Outdoor Range - 180m (650 Ft)
- Band - Dual
- Antenna (Type & Qty) - Unmentioned
General
Brand
Cambium
Model
Cambium cnpilot e410
Hardware
Network Standards
IEEE 802.11a,b,g,n,ac, Wave 2, 802.11 h,d,r,u,w
Data Transfer Rates
1267 Mbps
Outdoor Range
180m (650 Ft)
WAN Network Standard
Unmentioned
LAN Network Standard
Not Applicable
Interface
Number of WAN Port
1
Number of LAN Port
No
Wireless
Supported Protocols
VHT MCS rates, 16-QAM, 64-QAM, 256-QAM, HT20/40/80 MHz
Band
Dual
Frequency
2.4 - 5GHz
Bluetooth
No
Antenna (Type & Qty)
Unmentioned
Antenna Gain
2.4 GHz: 5.24 dBi , 5 GHz: 5.47 dBi
Antenna Placement
Internal
MU-MIMO Support
Yes
Management
SSID Numbers
32
Performance
OFDM/OFDMA
Yes
Email Alerts
Yes
Technical Info
MTBF
1500000 Hours
Security
Wireless Security
WPA2 (802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK, Open
Physical Security Lock
Yes
Security Lock Type
Kensington Lock Slot
Electrical
Max. Power Consumption
11.5W
Passive PoE Power Supply
802.3af
Environmental
Operating Temperature
0 Degree C - 50 Degree C
Operating Humidity
95% RH non-condensing
Storing/Storage Temperature
-40 Degree C - 70 Degree C
Physical Description
LED Indicators
Single Tri-color LED (amber, blue, green)
Mounting
Yes
Mount Options
Desktop/ Wall Mount/ Cielling
Dimensions
180 x 180 x 42mm
Color
White
Weight (gm)
384gm
Packet Contents
Cambium cnpilot e410, Desktop, Wall, cieling tile mount - included T-bar mount 14 mm x 24 mm x 38 mm (0.55 in x 0.94 in x 1.5 in) Ceiling Tile mount included
Warranty
Warranty Details
1 Year (Without Adapter)
Additional Info
Others
MIMO Streams: 2 x 2 MIMO streams., Concurrent Clients: 256, SSID: 16 SSIDs across 2 radios, Antenna gain: 4.55 dBi (2.4 GHz)/4.25 dBi (5 GHz), Multi-Hop Mesh: Yes, Supported on Indoor & Outdoor access points. Mesh auto-recovery supported, Polarization: Dual-linear, Antenna Coverage Omni (360degree), Ethernet Ports: One (1) x 1 Gigabit Ethernet (10/100/1000 Mbps), Power Supply: Standard 802.3af injector (supplied) or any PoE switch, Physical Lock: Kensington key hole, Max TX Power: +25 dBm, LED: Single LED window with tri color (Amber, Blue, Green) display
Specialty
Kensington key hole Physical Lock, +25 dBm Max TX Power, Single LED window with tri color (Amber, Blue, Green) display, Supported on Indoor & Outdoor access points, Mesh auto-recovery supported, 16 SSIDs across 2 radios
