CPU: Chipset: MT7621, Wireless: 5 GHz Wi-Fi Speed: 867 Mbps, 2.4 GHz Wi-Fi Speed: 300 Mbps, 5 GHz Wi-Fi Streams: 2T2R (2x2 MIMO), 2.4 GHz Wi-Fi Streams: 2T2R (2x2 MIMO), 5 GHz Antenna Gain Max: 5.99 dBi, 2.4 GHz Antenna Gain Max: 5.24 dBi, FEM or PA/LNA: 5 GHz: 2x Internal, 2.4 GHz: 2x Internal, Beamforming: True, Range Performance: Max: 170 m (558 ft), Indoor WiFi range varies depending on the layout and wall materials. See the Wall Performance spec for placement suggestions. Wall Performance: Two wooden walls with thickness < 10 cm (4 inches), one concrete wall with thickness < 20 cm (7 inches), Power Input: DC Jack, Power Power Methods: DC, DC: 12V 1A, Max Power Consumption (W): 9.12W, Idle Power Consumption (W): 3.58W, Package Content: WR1300E, Power Adapter, Ethernet Cable, Installation Guide, Wireless: Wi-Fi Standards: Wi-Fi 5, Max Wi-Fi Modulation: 256-QAM, Wi-Fi Efficiency: MU-MIMO, Wi-Fi Efficiency Note: MU-MIMO is available on 5 GHz, Max Capacity: 128, Recommended Client Upper Limit: 50. Max Wi-Fi Channel Width: 80 MHz, WPS: True, General Operation Modes: Wi-Fi Router, Access Point, Range Extender, WISP, Client, Mesh: Cudy Mesh, Mesh Backhaul: Wireless Backhaul, Wired Backhaul, Multi-Band Backhaul: true, Internet Failover Sequence: WAN, WISP, Network: QoS: Per-User Rate Limiting, DHCP: Address Reservation, DHCP Client List, Server, IP Versions: IPv4/IPv6, IPv6 Protocols: Relay, Dynamic (SLAAC/DHCPv6), Static (Fixed IP), Passthrough, 464xLAT, MAP-E, DS-Lite, IPTV/VLAN: Bridge, Tag VLAN, VoIP VLAN, IPTV VLAN, TTL Customization: Extend, Spoof, Custom, IGMP: IGMP Proxy, IGMP Snooping, Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ, Firewall: SPI Firewall, DoS Protection, Block PING, Application Layer Gateway: IPSec Passthrough, L2TP Passthrough, PPTP Passthrough, FTP Passthrough, TFTP Passthrough, H323 Passthrough, SIP Passthrough, RTSP Passthrough, Utilities: VPN Server: WireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP, VPN Client: WireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP. VPN Performance: OpenVPN Client (UL/DL): 22 / 24.7 Mbps, OpenVPN Server (UL/DL): 22 / 20.9 Mbps, WireGuard Client (UL/DL): 142 / 233.9 Mbps, WireGuard Server (UL/DL): 213 / 152 Mbps, DNS Options: DNS over TLS, Manual DNS, Rebind Protection, Override Clients` DNS, DNS over TLS Providers: Cloudflare, Google, Quad9, Custom, Captive Portal: True, Wake on LAN: True, Online Detection: True, Max Concurrent VPN Tunnels: IPSec: 20, PPTP/L2TP: 16, OpenVPN: 16, General Max Concurrent Sessions: 25000. Management All Devices Management: Wi-Fi Time Schedule, MAC Filter, IP/MAC Binding, Per-Device Management: Internet On/Off, VPN On/Off, Online Time Schedule, Device Rename, Content Management: Domain Filter, IP Filter,
