Feature
Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats. Max. decoding capability: 32 x 1080p@30 fps or 32 x 2MP@30 fps. Max. 384/384/384 Mbps incoming/recording/outgoing bandwidth. Supports IP cameras with a resolution up to 32 MP. Supports AcuPick with up to 32 channels. Supports N+M cluster,iSCSI. Support Raid0/1/5/6/10. AI by Recorder supports 2-channel face detection and recognition, up to 20 face databases and 20,000 face images; 4-channel perimeter protection; 8-channel SMD Plus. AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting. Supports EPTZ, and one-click arming and disarming.
Others
Operating Interface: Web, Local GUI, AI by Recorder: Face detection; face recognition; perimeter protection; SMD Plus, AI by Camera: Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map, AcuPick AI by Camera + Recorder: Max. 32-channel, 1 combined event per channel/s , Certifications: FCC: 47 CFR FCC Part15, SubpartB, Class A, CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014, CE-LVD: EN 62368-1: 2014 , Operating Temperature: -10 Degree C to +55 Degree C, Storage Temperature: -20 Degree C to +60 Degree C, Operating Humidity: 10%-93% (RH), Installation: Rack or desktop, General Alarm: Motion detection; privacy masking; local alarm, Anomaly Alarm: Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception, Intelligent Alarm: Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map, Alarm Linkage: Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email, Port: HDMI 2, VGA 2 , RS-485: 2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication) Multi-channel Playback: Up to 16 channels, Record Mode: General, motion detection; intelligent; alarm; POS, Backup Method: USB device and network, Playback Mode: Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) Browser: Chrome;IE;Safari;Edge;Firefox, Network Mode: Multi-address mode, load balance, fault tolerance and other network port binding modes, Third-party Camera Access: ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha ANPR by Camera (Number of Channels): 8 channels, License Plate Database Capacity: 1. Create up to 20,000 plate numbers. 2. Blocklist and allowlist Metadata Performance of AI by Camera (Number of Channels): 8 channels, Human Attributes: Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella, Motor Vehicle Attributes: License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location. Non-motor Vehicle Attributes, Vehicle model, vehicle color, number of persons, helmet. Face Database Capacity: Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. Face Recognition Performance of AI by Recorder (Number of Channels): 1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s 2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/s Face Recognition Performance of AI by Camera (Number of Channels): 16 channels , SMD Plus by Recorder, 8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change SMD Plus by Camera: 16 channels
