Hikvision DS-3E0518P-E/M 18 Port ( 16 Port 10/100/1000 PoE, 2 Port 10/100/1000 SFP Fiber Optic) Unmanaged PoE Switch
Product Id: 29.05.485.20
Brand
Hikvision
Special Price
Tk 19,200
Tk 19,200
Regular Price
Tk 20,720
EMI TK 1,727
Quick Overview
- Type - Network Switch
- Number of Total Port - 18 Port
- PoE - Yes
- Manageability - Unmanaged
- Network Standards - IEEE 802.3at/af standard, IEEE 802.3, IEEE 802.3u, and IEEE 802.3x
- Data Transfer Rate - 10/100/1000 Mbps
- Form Factor - Rackmount
General
Brand
Hikvision
Model
Hikvision DS-3E0518P-E/M
Type
Network Switch
Ports & Slots
Number of Total Port
18 Port
Gigabit Port
18
SFP Port
2
PoE Port
16
Technical Info
PoE
Yes
Manageability
Unmanaged
Interface(s)
16 x Gigabit PoE port, 2 x Gigabit SFP fiber optical port
Network Standards
IEEE 802.3at/af standard, IEEE 802.3, IEEE 802.3u, and IEEE 802.3x
Data Transfer Rate
10/100/1000 Mbps
Connector Type
16 x Rj45 port, 2 x Gigabit SFP port
Switching Capacity
Store-and-forward
Physical Description
Body Material
Metal
Body Color
Gray
Form Factor
Rackmount
Dimension
440 x 44 x 220.8 mm
Weight
2.50 kg
Packet Contents
Hikvision DS-3E0518P-E/M Switch, User Manual, Warranty Card
Power
Power Supply
100-240 VAC, 50/60 Hz, Max. 2.5 A
Approx. Power Consumption
150W (Max.), 25W (Idle)
Warranty
Warranty Details
1 year
Additional Info
Others
Operating Temperature: 0 Degree C to 45 Degree C, Storage Temperature -40 Degree C to 85 Degree C, Operating Humidity: 5% to 95% (no condensation), Relative Humidity: 5% to 95% (no condensation), Surge Protection: 6 KV, PoE Standard: IEEE 802.3af;IEEE 802.3at; PoE Power Pin: End-span: 1/2(+), 3/6(-), PoE Port: PoE: Ports 1 to 16, Max. Port Power: 30 W, PoE Power Budget: 125 W, Approval: EMC: FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015), Safety: UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017), Chemistry: CE-RoHS (201165EU); WEEE (201219EU); Reach (Regulation (EC) No.19072006)
Specialty
6 KV surge protection for PoE ports, PoE power management, Gigabit network access, Wire-speed forwarding, Store-and-forward switching, Solid high-strength metal she
Country Of Origin
China
Made in/ Assemble
China
N.B. Specification may differ with actual product. In that case, Ryans will execute full refund within 5 days.
