Others
Total harmonic distortion: 0.2% (Line in to Speaker out, Half power @1kHz, 3/4/8), 0.2% (Line in to Speaker out, Half Power @1kHz, 70V/100V, 120W/200W), Crosstalk: -70dB (MIC/LINE input to other MIC/LINE input), Control ports: RJ-45 (for DCP4V4S, DCP1V4S , DCP4S), Remote (3.5mm Euro block 3-pin), Input Level: Mic input: -56dBu (Sensitivity), -36dBu (Nominal), -8dBu (Max before clip) / Line input (unbalanced): -30dBV (Sensitivity), -10dBV (Nominal), +10dBV (Max before clip) / Line input (balanced): -24dBu (Sensitivity), -4dBu (Nominal), +24dBu (Max before clip), Output Level: -10dBV (LINE OUT, Nominal), Processors: Speaker EQ (VXS:Full Range, VXC, VXS10S/ST), HPF (150Hz), LPF (150Hz, 200Hz), Load protection: Power switch on/off: Mute the output*, Output voltage protection: Compress the output*, DC-fault: Power supply shutdown (*Restored automatically), Amplifier protection: Thermal: Limit the output Mute Shutdown, Over current: Mute the output, Integrated power limit: Compress the output (Restored automatically), Power supply protection: Thermal: Power supply shutdown, Over voltage: Power supply shutdown, Over current: Limit the output Power supply shutdown (Restored automatically), Amplifier class: Class D, Cooling: Conventional cooling, bottom to up airflow, Certificate: ENERGY STAR, Operating Temperature: 0 to + 40 degree C, Storage Temperature: -20 to + 60 degree C, Rack-mountable when ensuring sufficient ventilation above and below the unit.
