Phantom power: +48 V, Mono[MIC/LINE]: 4, Stereo[LINE]: 3, STEREO OUT: 2, MONITOR OUT: 1, PHONES: 1, AUX SEND: 1, Bus: Stereo: 1, AUX[FX]: 1, Input Channel Function: 26 dB (Mono) PAD, 80 Hz, 12 dB/oct (Mono/Stereo: MIC only) HPF, COMP, 1-knob compressor Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB, Attack time: approx. 25 msec, Release time: approx. 300 msec, EQ HIGH: Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving, EQ MID: Gain: +15 dB/-15 dB, Frequency: 2.5kHz peaking, EQ LOW: Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving, PEAK LED: LED turns on when post EQ signal reaches 3 dB below clipping, Level Meter: 2 x 7 -segment LED meter [PEAK, +10, +6, 0, -6, -10, -20 dB], Total harmonic distortion: 0.02 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +24dBu (1kHz), GAIN knob: Min, Frequency response: +0.5 dB/-1.0 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min, Hum & noise level: -128 dBu (Mono Input Channel, Rs: 150, GAIN knob: Max), Residual output noise: -102 dBu (STEREO OUT, STEREO LEVEL knob: Min), Crosstalk: -83 dB, Power requirements: PA-10 (AC 38 VCT, 0.62A, Cable length = 3.6 m) or equivalent recommended by Yamaha, Operating Temperature: 0 to +40 degreeC.
