Feature
Max. 16 Mic / 20 Line Inputs (12 mono + 4 stereo), 4 GROUP Buses + 1 Stereo Bus, 4 AUX (incl. FX), D-PRE mic preamps with an inverted Darlington circuit, 1-Knob compressors, High-grade effects: SPX with 24 programs, 24-bit/192kHz 2in/2out USB Audio functions, Works with the iPad (2 or later) through the Apple iPad Camera Connection Kit / Lightning to USB Camera Adapter,
Others
On-board processors: SPX algorithm: 24 programs, PARAMETER control:1, FOOT SW:1 (FX RTN CH on/off), Digital I/O: USB Audio Class 2.0 compliant Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit, Input channel - Mono[MIC/LINE]: 12, Mono/Stereo[MIC/LINE]: 4, Output Channels: STEREO OUT - 2, MONITOR OUT - 1, PHONES - 1, AUX SEND- 4, GROUP OUT - 4, Bus: Stereo: 1, GROUP: 4, AUX: 4 (incl. FX), Input Channel Function: PAD-26 dB (Mono), HPF-80 Hz, 12 dB/oct (Mono/Stereo: MIC only), COMP: 1-knob compressor (Gain/Threshold/Ratio) Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB Attack time: approx. 25 msec, Release time: approx. 300 msec, EQ HIGH - Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving, EQ MID Gain: +15 dB/-15 dB, Frequency: Mono 250 Hz - 5 kHz peaking, Stereo 2.5 kHz peaking, EQ LOW -Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving, PEAK LED - LED turns on when post EQ signal reaches 3 dB below clipping, Level Meter: 2x12 -segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB], Total harmonic distortion : 0.03 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.005 % @ +24dBu (1kHz), GAIN knob: Min, Frequency response: +0.5 dB/-1.5 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min, Hum & noise level: Equivalent input noise: -128 dBu, Residual output noise: -102 dBu (STEREO OUT, STEREO master fader: Min)
Specialty
Includes Cubase AI DAW software download version, PAD switch on mono inputs, +48V phantom power, XLR balanced outputs, Internal universal power supply for world-wide use, Rack Mount Kit Included, Metal chassis
