Fader Configuration: 32 + 1 (Master), Input Channels: 48 (40 mono + 2 stereo + 2 return), Aux Buses: 20 (8 mono + 6 stereo) , Stereo Buses: 1, Sub Buses: 1, Input channel functions: 8 DCA Groups, Inputs: 32 mic/line (XLR/TRS combo) + 2 stereo line (RCA pin), Outputs16 (XLR), Expansion slots: 1, DSP: 8 Effects + 10 GEQ, USB: 34x34 USB Audio Interface, 2-track recording via USB Storage Device, Sampling frequency rate: 48 kHz (Internal), Signal delay: Less than 2.6 ms, INPUT to OMNI OUT, Fs=48 kHz, Fader: 100 mm motorized, Resolution = 10-bit, +10 dB to -138 dB, - infinity dB all faders, Total harmonic distortion: Less than 0.05% 20 Hz-20 kHz @+4 dBu into 600 , INPUT to OMNI OUT, Input Gain=Min. (Measured with a -128 dB/octave filter@80 kHz), Frequency response: +0.5, -1.5 dB 20 Hz-20 kHz, refer to +4 dBu output @1kHz, Input to Omni Out. Dynamic range: 110 dB typ., DA Converter, 107 dB typ., INPUT to OMNI OUT, Input Gain=Min. Equivalent input noise: -128 dBu typ., Input Gain=Max. (Measured with an A-Weight filter), -85 dBu, ST master off (Measured with an A-Weight filter), Crosstalk: -100 dB (Measured with a -30 dB/octave filter@22 kHz), adjacent INPUT/OMNI OUT channels, Input Gain=Min. Operating temperature range: 0-40 Degree C, Storage temperature range: -20-60 Degree C.
